| 機床型號 | 單位 | G1625 | G2225 | G3025 | G4025 | G5025 | G6025 | |
| 加工範圍 | X軸行程 | mm | 1600 | 2200 | 3000 | 4000 | 5000 | 6000 |
| Y軸行程 | mm | 2500 | ||||||
| Z軸行程 | mm | 1000/ 12000 | ||||||
| 主軸鼻端至工作臺距離 | mm | Z1,000:110~1,110/Z1,200:110~1,310 | ||||||
| mm | Z1,000:200~1,200/Z1,200:200~1,400 | |||||||
| mm | Z1,000:160~1,160/Z1,200:160~1,360 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1,440 | |||||||
| mm | Z1,000;275~1,275/Z1,200:275~1,475 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1,440 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1.440 | |||||||
| mm | Z1,000:225~1,225/Z1,200:225~1,425 | |||||||
| mm | Z1,000:225~1,225/Z1,200:225~1,425 | |||||||
| 雙立柱間距離(門寬) | mm | 3,400 | ||||||
| 工作臺規格 | 工作臺面積 | mm | 1,600*2,500 | 2,200*2,500 | 3,600*2,500 | 4,000*2,500 | 5,000*2,500 | 6,000*2,500 |
| T型槽（寬度*數量*間距） | mm | 28*11*250 | 28*15*250 | 28*19*250 | 28*23*250 | |||
| 工作臺最大載重 | kg/cm² | 3,000 | ||||||
| 主軸規格 | 主軸 | / | H810S-02-15 | |||||
| 主軸功率(S1/S6) | kw | 50/65 | ||||||
| 主軸轉速 | rpm | 12000/15000/20000/24000 | ||||||
| 主軸錐孔 | / | HSK A63/HSK-A100 | ||||||
| 主軸扭矩(S1/S6) | Nm | 95.5/ 124 | ||||||
| 進給 | 切削進給速度 | m/min | 1-20 | |||||
| 快速進給速度 | m/min | XY:32/ Z:20 | ||||||
| 精度 | 定位精度 | mm | ±0.005/全行程 | ±0.007/全行程 | ±0.008/全行程 | |||
| 定位精度 | mm | P0.008 | P0.010 | P0.012 | P0.015 | |||
| 重複定位精度 | mm | ±0.002 | ||||||
| 重複定位精度(VD13441) | mm | PS0.006 | PS0.008 | PS0.012 | ||||
| 刀庫 | 容量 | T | 20/32/40/60 | |||||
| 最大刀徑-相鄰刀 | mm | HSK-A63:Ф75 /HSK-A100:Ф125 | ||||||
| 最大刀徑-隔空刀 | mm | HSK-A63:Ф130/HSK-A100:Ф250 | ||||||
| 最大刀長 | mm | 300 | ||||||
| 最大刀重 | kg | HSK-A63: 8,HSK-A100:15 | ||||||
| 機器規格 | 機器尺寸 | m | 6.9*8.6*5.5 | 7.5*8.6*5.5 | 9.1*8.6*5.5 | 10.1*8.6*5.5 | 11.1*8.6*5.5 | 12.1*8.6*5.5 |
| 機器重量 | kg | 43,500 | 48,500 | 48,000 | 57,500 | 66,500 | 76,500 | |
| 機床型號 | 單位 | G2232 | G3032 | G4032 | G5032 | G6032 | ||
| 加工範圍 | X軸行程 | mm | 2,200 | 3,000 | 4,000 | 5,000 | 6,000 | |
| Y軸行程 | mm | 3,200 | ||||||
| Z軸行程 | mm | 1，000/1，2000 | ||||||
| 工作臺規格 | 主軸鼻端至工作臺距離 | mm | Z1,000:110~1,110/Z1,200:110~1,310 | |||||
| mm | Z1,000:200~1,200/Z1,200:200~1,400 | |||||||
| mm | Z1,000:160~1,160/Z1,200:160~1,360 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1,440 | |||||||
| mm | Z1,000;275~1,275/Z1,200:275~1,475 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1,440 | |||||||
| mm | Z1,000:240~1,240/Z1,200:240~1.440 | |||||||
| mm | Z1,000:225~1,225/Z1,200:225~1,425 | |||||||
| mm | Z1,000:225~1,225/Z1,200:225~1,425 | |||||||
| 雙立柱間距離(門寬) | mm | 3,900 | ||||||
| 工作臺規格 | 工作臺面積 | mm | 2,200 *3,200 | 3.000*3,200 | 4,000*3,200 | 5,000*3,200 | 6.000*3.200 | |
| T型槽（寬度*數量*間距） | mm | 28*13*250 | 28*11*250 | 28*15*250 | 28*19*250 | 28*23*250 | ||
| 工作臺最大載重 | kg/cm² | 3,000 | ||||||
| 主軸 | 主軸 | / | H810S-02-15 | |||||
| 主軸功率(S1/S6) | kw | 50/65 | ||||||
| 主軸轉速 | rpm | 15,000 | ||||||
| 主軸錐孔 | / | HSK-A100 | ||||||
| 主軸扭矩S1/S6) | Nm | 95.5/ 124 | ||||||
| 進給 | 切削進給速度 | m/min | 1-20 | |||||
| 快速進給速度 | m/min | XY:32/Z:20 | ||||||
| 精度 | 定位精度(JIS-B6333) | mm | ±0.005/全行程 | ±0.007/全行程 | ||||
| 定位精度(VD13441) | mm | P0.008 | P0.010 | P0.012 | P0.015 | |||
| 重複定位精度(JIS-B6333) | mm | ±0.002 | ||||||
| 重複定位精度(VD13441) | mm | PS0.006 | PS0.008 | PS0.012 | ||||
| 刀庫 | 容量 | T | 20/32/40/60 | |||||
| 機器規格 | 機器尺寸 | m | 7.5*9.1*5.5 | 9.1*9.1*5.5 | 10.1*9.1*5.5 | 11.1*9.1*5.5 | 12.1*9.1*5.5 | |
| 機器重量 | kg | 46,000 | 45,500 | 55,500 | 64,000 | 73,500 | ||
| 由於產品技術不斷更新，以上參數僅供參考 | ||||||||
